AEG MODICON B805-016 Input/Output Module

Product manual:

AEG MODICON B805-016 Input/Output Module

B805-016 is a common integrated I/O module in Modicon system, which integrates input and output functions,
Used to establish a bidirectional signal channel between the controller and the field device.

Main functions of the module

Input signal acquisition
Capable of receiving signals from sensors, buttons, limit switches, protective contacts, and other devices, and transmitting them in real-time to the CPU.

Output action control
According to the PLC program logic output instructions, drive relays, solenoid valves, small actuators and other equipment to perform actions.

Bidirectional data synchronization
Both input and output states can be synchronized with the controller through the backplane for monitoring or logical judgment.

Structure and Characteristics

The number of input and output channels is balanced, which can meet the general industrial site requirements.

The input end has anti-interference design and can adapt to complex electromagnetic environments on site.

The output drive capability is stable and suitable for frequent or periodic device control.

The module adopts a standard slot structure and is compatible with series racks such as Modicon 800/984.

The wiring terminal layout is clear, convenient for installation, maintenance, and quick replacement.

Typical application scenarios

Local control of small and medium-sized devices

Process points within the same area that require both detection signals and execution of actions

Rhythmic equipment such as packaging, mechanical processing, and conveying systems

Conventional control processes in industries such as chemical, building materials, and food processing

Point expansion and maintenance of the old Modicon system

Advantages of use

Integrate input and output into the same module to reduce the number of modules

Durable structure, suitable for long-term continuous work

Easy for on-site diagnosis, clear channel status

Easy replacement and quick resumption of production

Excellent compatibility in old industrial control systems, easy to use for replacing engineering

AEG MODICON B805-016  Product details picture:
