AEG MODICON CGD24-R brushless servo motor

Product manual:

Introduction to AEG Modicon CGD24-R Brushless Servo Motor
CGD24-R is a high-performance brushless servo motor from the AEG Modicon series, designed specifically for precision motion control in industrial automation systems. It achieves high-precision control of position, speed, and torque by cooperating with drivers and controllers, and is widely used in automated production equipment and mechanical motion systems.

functional positioning

Provide high-precision rotational motion, suitable for positioning, transmission, and synchronous control.

Cooperate with the motion control module to achieve closed-loop position, speed, and torque control.

Can receive instructions from the controller to achieve continuous or step-by-step motion.

Used to replace traditional brush motors, reduce maintenance requirements, and improve reliability.

Technical Features

Brushless design, low friction, high efficiency, and long lifespan.

High precision encoder feedback achieves closed-loop motion control to ensure action accuracy.

Can withstand frequent start stop and high load operation, suitable for industrial production environments.

Low noise and low vibration design, suitable for application scenarios that require high mechanical stability.

Compatible with Modicon series motion control modules, it can be quickly integrated into existing control systems.

Structure and usage characteristics

Compact body, easy to install in control cabinets or mechanical equipment.

Easy wiring, standardized interfaces, and convenient connection with drivers and controllers.

Industrial grade structural materials, resistant to high temperatures, dust and vibration, suitable for complex industrial environments.

Status indication facilitates monitoring of operational status and maintenance.

Typical application scenarios

Precise positioning of automated robotic arms or conveyor systems.

High speed motion control of packaging, sorting, and assembly lines.

High precision and high reliability rotary actuators are required in industrial production equipment.

A closed-loop control system that collaborates with Modicon motion control modules and drivers.

AEG MODICON CGD24-R Product details picture:

CGD24-R

AEG MODICON CGD24-R product video
