AEG MODICON TSX3721100 processor module

Product manual:

Processor Module - Function and Feature Description**

TSX3721100 belongs to the core processor module of AEG/Modicon TSX series, which is the brain unit in PLC control systems, responsible for executing logic programs, managing I/O data, and coordinating communication tasks. It is suitable for medium to large automation systems and can stably handle multi-channel I/O and complex logic.

1. Core processing functions

The module is mainly responsible for:

Execute user logic program

Scan input/output module

Coordinate sequential control, timing, and counting tasks

Manage data communication and system scheduling

Ensure that the control system operates stably according to the design logic.

2. Industrial grade reliability

TSX3721100 is designed for industrial environments and features include:

Long term continuous stable operation

Strong ability to resist electromagnetic interference

Can withstand temperature changes and mechanical vibrations

High reliability, low failure rate

Suitable for continuous operation systems in power, metallurgy, chemical, and mechanical production lines.

3. Compatible with I/O modules

The processor module can be used in conjunction with various I/O modules:

Digital input/output module

Analog module

communication module

Remote I/O expansion module

Implement a complete distributed control system architecture with clear structure, easy to debug and maintain.

4. Program storage and execution

The module provides sufficient storage space:

Save ladder diagram or logic block program

Support functions such as timers, counters, sequence control, etc

The scanning execution cycle is stable, ensuring that the control task runs at the predetermined pace

AEG MODICON TSX3721100  Product details picture:

TSX3721100

AEG MODICON TSX3721100 product video
