AIP578 Optical Link Transmission Module

Model: AIP578
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AIP578 Optical Link Transmission Module

Product manual:

AIP578 Optical Link Transmission Module
AIP578 is an industrial grade optical link transceiver module designed by Yokogawa Electric for CENTUM CS/VP distributed control systems. It is used to achieve electrical optical signal conversion and long-distance, anti-interference data transmission in V net/IP networks.
Core Features
Compatible with Yokogawa CENTUM CS/VP system, dedicated V net/IP network optical communication
Multi mode fiber (MMF) transmission, SC plug-in fiber interface
850nm wavelength, transmission power -18~-11dBm, reception sensitivity ≤ -27dBm
Maximum transmission distance of 2km (50/125 μ m multimode fiber)
Industrial grade wide temperature operation, suitable for environments ranging from -20 ℃ to+70 ℃
Hardware redundancy design, supporting seamless switching between primary and backup
Strong resistance to electromagnetic interference, suitable for high noise industrial sites
Modular card insertion structure, easy installation and maintenance
Built in link monitoring and fault diagnosis for quick problem localization
Compliant with international standards such as CE and UL, with industrial level 4 design
Low power consumption, long lifespan, capable of continuous operation for 7 × 24 hours
Support collaborative work with Yokogawa RIO I/O series modules
Typical Applications
Expansion of Optical Link in Yokogawa CENTUM CS/VP DCS System
Long distance communication for process control in chemical, petrochemical, and power industries
Isolation transmission of industrial networks in high electromagnetic interference environments
Distributed control system networking between factory workshops and equipment
Upgrading of Optical Communication and Replacement of Spare Parts for Old DCS Systems
High reliability industrial scenarios such as oil and gas, metallurgy, and papermaking
This module has stable transmission, strong anti-interference, and reliable redundancy, and is the core component for achieving long-distance and high security optical communication in the Yokogawa DCS system.
