ALCATEL LUCENT 3CM02420ABAA Communication Module

Product manual:

ALCATEL-LUCENT 3CM02420ABAA Communication Module Product Overview and Application Fields
The 3CM02420ABAA from Alcatel Lucent (now under Nokia) is a communication module,
Usually used for telecommunications grade network equipment, providing data transmission, interface expansion, or control management functions.

1. Main application areas
(1) Optical Transmission Network (OTN/DWDM)
Equipment model: May be used for optical transmission platforms such as 1830 Photonic Service Switch (PSS) or 1626 Light Manager (LM).

Function:

Optical channel management (wavelength allocation, optical power adjustment).

Electrical layer cross connection (ODU/OTN switching).

Performance monitoring (bit error rate, optical signal-to-noise ratio analysis).

(2) IP/MPLS Routing and Switching Equipment
Equipment model: may be integrated into 7750 SR (Service Router) or 7450 ESS (Ethernet Service Switch).

Function:

High speed data forwarding (such as 100G/400G interfaces).

Traffic engineering (MPLS-TE, SRv6).

Redundant backup (main control board hot switching).

(3) Mobile communication (4G/5G backhaul and core network)
Application scenarios:

5G pre transmission (eCPRI), mid transmission (IP-RAN), and backhaul (PTN/IP/MPLS).

Core Network User Plane (UPF) or Control Plane (AMF/SMF) devices.

Function:

Low latency data transmission (uRLLC).

Time synchronization (1588v2, SyncE).

(4) Data Center Interconnection (DCI)
Function:

Large capacity data exchange (supporting MACsec encryption).

Pluggable optical modules (such as QSFP-DD/CFP2).

2. Key characteristics of the module (speculated)
Interface type: May support high-speed optical ports (100G/400G) or electrical ports (10G/25G).

Protocol support: OTN, Ethernet, MPLS, IP, etc.

Reliability: Supports hot swapping, redundant power supply, and automatic fault detection.

Management method: It can be configured through CLI, SNMP, NETCONF/YANG.

3. Technological development trends
Evolution towards higher bandwidth: Supports 800G/1.6T optical modules.

SDN/NFV integration: Supports virtualized network functionality (VNF).

AI operation and maintenance: combined with Nokia MantaRay NMS to achieve intelligent monitoring.

Open Optical Network: Supports standards such as OpenROADM and OpenZR+.

Product details picture:
