AMAT 0100-00025 power module

Product manual:

AMAT 0100-00025 power module
Product Overview

AMAT (Applied Materials) 0100-00025 power module is a core electrical power supply unit used in semiconductor manufacturing equipment to provide stable and reliable DC or AC power to various sub modules inside the equipment. It is usually integrated into control boxes, chassis control boxes, or independent power cabinets to supply power to key modules such as heaters, pumps, pneumatic valves, RF modules, controllers, etc., ensuring stable equipment operation, process accuracy, and system safety.

Technical parameters (typical direction, specific data should refer to the original factory information)

Input power supply: Industrial standard AC power supply

Output type: DC/AC power output, multiple adjustable channels

Rated power: suitable for high-power process modules

Protection functions: overcurrent protection, overvoltage protection, short circuit protection

Interface: Can connect with device control system and security interlock system to achieve remote monitoring

Installation method: Modular, easy to integrate, maintain, and replace on site

Environmental adaptability: high temperature resistance, vibration resistance, suitable for clean room process environment

Application scenarios

Controller and chassis control box power supply

For the controller PCB、 Interlocking modules and other components provide stable power supply

Ensure the normal operation of internal electronic modules

Deposition process (CVD/PVD/ALD)

Provide high-precision power supply for heaters, pumps, and gas valves

Support temperature and flow control during thin film deposition process

Etching process equipment

Power supply for RF module, pressure sensor, and flow control module

Ensure stable etching power and gas control

Ion implantation system

Provide power for ion source, scanning system, and beam monitoring module

Ensure consistent injection dose and uniformity

Factory Automation and Safety Systems

Cooperate with interlocking and monitoring systems to achieve equipment abnormal power-off protection

Improve operational safety and process continuity

AMAT 0100-00025 Product details picture:

0100-00025
