AMAT 0190-27748 Control Video Switch

Product manual:

AMAT 0190-27748 Control Video Switch
Product Overview

AMAT (Applied Materials) 0190-27748 Control Video Switch is a video signal switching and control module used in semiconductor manufacturing equipment. It is mainly used to monitor the internal processes or mechanical movements of equipment. By switching multiple video signal sources, the image signals of cameras, monitoring probes, or process observation points are transmitted to the operation interface or recording system to achieve equipment status monitoring, process observation, and safety management.

Technical parameters (typical direction, specific data should refer to the original factory information)

Input/Output: Multiple video inputs, multiple outputs, switchable

Signal type: Analog or digital video signal

Control method: Switch the video source through the control system or manual interface

Interface: Connect with device monitoring system, controller or operation terminal

Installation method: Modular design, can be integrated into the control box or equipment chassis

Environmental adaptability: Suitable for clean room environment and industrial temperature range

Application scenarios

Deposition process (CVD/PVD/ALD)

Monitor the status of reaction chambers or critical modules

Real time observation of sedimentation process to ensure process accuracy

Etching process equipment

Switching between monitoring videos for observing etching chambers or gas flow control points

Support process parameter adjustment and abnormal troubleshooting

Ion implantation system

Real time monitoring of ion source, scanning system, and beam path

Improve the visualization and operational safety of the injection process

Equipment maintenance and operation

Switching monitoring perspectives for easy on-site maintenance and fault diagnosis

Support operators to quickly locate equipment abnormalities

Factory Automation and Safety Management

Combined with interlocking system and operation interface, achieve remote monitoring

Improve equipment operation safety and process controllability

AMAT 0190-27748 Product details picture:

0190-27748

AMAT 0190-27748 product video
