AMAT Applied Materials 0050-30838 Welded Valve Assembly

Product manual:

Product Overview

AMAT 0050-30838 Welding Valve Manifold 3 Station Left is a component used for precision fluid control in semiconductor equipment. It is responsible for the distribution and switching of multi-channel gases or liquids, ensuring the stability and reliability of the process fluid system.

Technical parameters (based on naming speculation)

Model: 0050-30838

Type: 3 Station Weldment Valve Manifold

Installation direction: Left

Material: High purity stainless steel, suitable for high-purity gases or liquids

Function: Multi channel fluid distribution, valve switching, flow path control

Application field

Semiconductor Manufacturing Equipment

The precise distribution and switching of gases or liquids ensure accurate and error free process fluid management.

Chemical Vapor Deposition (CVD) and Physical Vapor Deposition (PVD) systems

Control the flow and distribution of reaction gases to ensure deposition uniformity.

Chemical Mechanical Polishing (CMP) System

Manage the flow of polishing solution or auxiliary liquid to maintain process stability.

Product advantages

Multi channel design: supports three channel fluid distribution to improve system flexibility.

Welded structure: High sealing and structural stability, reducing the risk of leakage.

High purity material: meets the strict requirements of the semiconductor industry for materials.

Compact design: saves internal space of the equipment and facilitates installation.

Precautions

Interface matching: Ensure that the interface type and size are consistent with the existing system.

Sealing inspection: Regularly check the sealing condition of welding parts and interfaces.

Cleaning and maintenance: Keep the valve assembly clean to avoid impurities affecting fluid flow.

Compatibility confirmation: When replacing, confirm that the new valve assembly is compatible with the system to avoid malfunctions.

AMAT Applied Materials 0050-30838  Product details picture:

0050-30838

AMAT Applied Materials 0050-30838 product video
