AMAT Applied Materials 0100-35346 Relay Module

Brand: AMAT Applied Materials
Model:0100-35346
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AMAT Applied Materials 0100-35346 Relay Module

Product manual:

Product Overview

AMAT Applied Materials 0100-35346 Relay Module is an industrial grade control module mainly used for electrical isolation, signal switching, and load control in semiconductor manufacturing equipment. It can provide safe and reliable electrical isolation between the control system and the actuator, allowing high voltage/high current signals to be safely triggered through low voltage control signals, ensuring the safety and stability of equipment operation.

Technical parameters (typical features, specific parameters are subject to physical or official information)

Product type: Relay Module

Main functions:

Signal switching and isolation

Control high voltage/high current loads

Multi-speaker output

Interface type: Modular slot or screw terminal interface, compatible with AMAT system

Electrical characteristics:

Working voltage range: Depending on the module design, it can be 24V DC, 110V AC, or other industrial voltages

Rated current: According to the module design, it is generally 5A-10A

Contact type: normally open (NO), normally closed (NC) or combination type

Mechanical characteristics: Industrial grade PCB or DIN rail installation, suitable for factory environment

Application scenarios

Semiconductor equipment control: used to control actuators such as pumps, valves, motors, etc., to achieve automated operations.

Signal isolation and safety: Isolate the low-voltage signal of the control system from the high-voltage load circuit to prevent interference and damage.

System Expansion: Supports multiple control signal outputs for easy device function expansion.

Equipment protection: Through the switching function of relays, overcurrent, overvoltage and other protection actions are achieved.

Product advantages

High reliability: Industrial grade design, suitable for long-term operating environments in semiconductor factories.

Electrical isolation: Ensure safe isolation between the control system and the load circuit, reducing the risk of equipment failure.

Modular design: easy to install, replace, and maintain quickly.

Strong compatibility: Deeply matched with AMAT's original control and signal modules to ensure system stability.
