AMAT Applied Materials 0100-90708 Vacuum Control Interlock PCB Card

Brand: AMAT Applied Materials
Model:0100-90708
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AMAT Applied Materials 0100-90708 Vacuum Control Interlock PCB Card

Product manual:

Product Overview

AMAT Applied Materials 0100-90708 Vacuum Control Interlock PCB Card is a safety and control module used in semiconductor manufacturing equipment. It is mainly used for monitoring and controlling vacuum systems, ensuring that relevant control signals are automatically cut off or protective actions are triggered when the vacuum chamber pressure is abnormal or the system does not reach a safe state, thereby ensuring the safety of process equipment and operators. This PCB card typically collaborates with vacuum pumps, sensors, main control systems, and interlock modules to form a complete vacuum safety control loop.

Technical parameters (typical features, specific parameters need to refer to physical objects or official materials)

Product Type: Vacuum Control Interlock PCB Card

Main functions:

Monitor the pressure and status of the vacuum chamber

Realize interlocking and safety protection of vacuum system

Collaborate with the host and I/O modules to achieve automated control

Interface type: Modular electronic interface, compatible with AMAT system backplane or control rack

Electrical characteristics:

Quickly respond to signal changes to ensure real-time safety interlocking

Support low voltage control signal input and output

Anti interference design, suitable for industrial environments

Mechanical characteristics: Industrial grade PCB size, convenient for modular installation and maintenance

Safety features: overvoltage protection, abnormal state alarm, and emergency shutdown function

Application scenarios

Vacuum chamber control: Monitor the vacuum status of the equipment to ensure stable process conditions.

Process equipment safety protection: Trigger interlocking in case of abnormal pressure or unprepared vacuum system to prevent equipment misoperation.

System integration: Collaborate with vacuum pumps, pressure sensors, interlock modules, I/O modules, and the host to form a complete closed-loop control system.

Equipment maintenance and upgrade: Modular design facilitates quick replacement or system debugging.
