AMAT Applied Materials 0120-90622 Controller

Product manual:

AMAT 0120-90622 Controller
Product Overview

The AMAT 0120-90622 controller is a key control unit in Applied Materials semiconductor equipment, mainly used to manage the operation of sub modules such as process chambers, gas panels, and power systems. It achieves precise control and real-time monitoring of complex process parameters through high-speed signal processing and multi-channel input/output interfaces, ensuring process stability and consistency. This module is usually installed in the device's main control architecture and is the core of system logic and execution control.

Technical parameters (inferred general characteristics)

Control function: Supports digital and analog input and output, with the ability to collect process parameters and control logic

Processing capability: Built in high-performance processor or programmable logic circuit to meet the real-time response requirements of semiconductor processes

Interface support: Can communicate and link with devices such as gas panels, vacuum pumps, RF power supplies, temperature control units, etc

Power characteristics: Low voltage DC power supply (typical+24VDC), with overvoltage and overcurrent protection

Stability: Meets the requirements for use in clean room environments, with anti-interference and long-term operation capabilities

Application scenarios

Core control of semiconductor process equipment

Subsystem coordination for CVD, PVD, ALD, etching, cleaning and other equipment

Responsible for controlling key parameters such as process gas, temperature, vacuum degree, RF power, etc

Equipment safety and interlock control

Cooperate with relay module and gas panel analysis module to perform safety interlock and protection functions

Avoid operating equipment in non safe conditions

Precise adjustment of process parameters

Provide real-time closed-loop control to maintain stability and repeatability of process conditions

Ensure consistency of results such as thin film deposition and etching profiles

Run data collection and diagnosis

Real time collection of process and equipment operation data

Support predictive maintenance to improve equipment utilization rate

AMAT Applied Materials 0120-90622 Product details picture:

0120-90622

AMAT Applied Materials 0120-90622 product video
