AMAT Applied Materials 0190-09368 connector

Product manual:

1、 Product Overview

AMAT 0190-09368 Connector Assembly is an industrial grade connector component used in Applied Materials semiconductor equipment for signal, power, or control interface connections.

Its main function is to achieve reliable electrical connections between various electronic modules inside the device, and ensure stable and safe signal and power transmission in harsh environments such as high temperature, low pressure, and strong electromagnetic interference.

2、 Product Technical Features

High reliability design

Adopting industrial grade metal casing and high-temperature resistant insulation materials;

Anti loosening structure, strong seismic performance, suitable for internal vibration environment of vacuum equipment.

Excellent electrical performance

Low contact resistance (typical value<5 m Ω);

High insulation and voltage resistance performance, up to 500V~1000V level;

Ensure signal integrity and reduce crosstalk and interference.

High temperature resistance and vacuum compatibility

The pins and housing are made of nickel plated copper alloy or stainless steel material;

The insulation part is made of high-performance polytetrafluoroethylene (PTFE) or alumina ceramic;

Suitable for connecting environments inside and outside vacuum chambers, without producing gas evaporation or particles.

Multi channel design

Support multi-core pin configuration (typically 10 Pin/20 Pin/24 Pin/32 Pin optional);

Capable of simultaneously transmitting multiple data channels such as power supply, analog signals, and control signals.

Strong protective performance

The protection level can reach IP65- IP67;

Anti static, dust-proof, and splash proof design, suitable for clean room environments.

Quick locking structure

Adopting a threaded locking ring or Bayonet locking design;

Easy insertion and removal, uniform contact pressure, ensuring long-term stable contact.

Modular compatibility

Compatible with AMAT series control modules and driver modules (such as 0190-16633 magnet driver, 0190-25423 power module, etc.);

Can be interchanged with standard MIL-C-5015, Cannon, or ITT series military grade connectors.
