AMAT Applied Materials 0190-25423 DC Power Supply Module

Brand: AMAT Applied Materials
Model:0190-25423
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

AMAT Applied Materials 0190-25423 DC Power Supply Module

Product manual:

1、 Product Overview

AMAT Applied Materials 0190-25423 DC Power Module is a high-performance DC power unit designed specifically for semiconductor manufacturing equipment.
It is used to provide stable DC power output for plasma power supplies, vacuum heating systems, gas control panels, and chamber controllers, and is one of the key energy conversion components in AMAT systems.

2、 Technical parameters
Project parameter description
Product model 0190-25423
Product type: DC Power Supply Module
Input voltage AC 200-240 V, single-phase or three-phase, 50/60 Hz
Output voltage range DC 0-48 V (typical), adjustable
Output current range 0-20 A (depending on configuration)
Rated power 800-1000 W (typical value)
Voltage regulation rate ≤ 0.5%
Current regulation rate ≤ 1%
Output ripple and noise ≤ 50 mVp-p
Protection functions include overcurrent protection (OCP), overvoltage protection (OVP), over temperature protection (OTP), and short circuit protection
Cooling method: forced air cooling with internal cooling fan
Interface form: Backboard slot connection/Front end signal control interface
Indication and monitoring LED status display, voltage/current monitoring signal output
Working temperature: 0 ° C to 50 ° C
Typical size 3U modular rack size (approximately 130 × 220 × 350 mm)
Weight approximately 5-7 kg (including heat dissipation components)
3、 Application scenarios

CVD/PVD system power distribution unit
Provide stable DC power supply for the heating system, bias electrode, and RF power controller inside the vacuum chamber.

Plasma etching equipment
Used to drive bias control circuits for plasma generation modules or electrostatic chucks (ESC).

Gas flow and valve control system
Power supply for driving solenoid valves, mass flow controllers (MFCs), and sensor interfaces.

Main control cabinet and chassis power system
As an auxiliary DC power supply, it supplies power to logic boards, signal amplification units, etc.
