AS-BVRC-200 Counter Input Module

Product manual:

Schneider AS-BVRC-200 is a counter input module for Modicon series programmable controllers, mainly used for counting and processing pulse signals or digital signals in industrial automation systems. Here is its main information and application overview:

Basic Parameters

Module type: Counter input module

Series: Modicon AS Series

Number of channels: usually provides 2 counting channels

Input type: Digital pulse input, capable of processing square wave, pulse signal or switch signal

Counting mode: Supports rising edge, falling edge, and double-sided edge counting, configurable

Maximum input frequency: typically up to several kHz (refer to manual for details)

Interface: Connected to Modicon PLC CPU module through backplane bus

Working voltage: Compliant with Modicon bus standard, typically 24 V DC

Features and Functions

Capable of accurately counting high-speed pulse signals

Supports multiple counting modes (one-way counting, two-way counting, cumulative counting)

Can be directly used for signal acquisition of sensors, encoders, switches, etc

Seamless integration with PLC system to achieve high-speed input data processing

Provide status indicator lights for on-site diagnosis

Applicable scenarios

Industrial assembly line production counting

Speed monitoring and positioning system

Material counting or cumulative statistics in automated machinery

In situations where high-speed pulse signals need to be input into a PLC for processing and control

AS-BVRC-200 Product details picture:
