ASEM HT2150/S0 screen panel
Brand:ASEM
Model:HT2150/S0
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
ASEM HT2150/S0 screen panel
Product manual:
ASEM HT2150/S0
[Product Type]
Industrial grade touch screen human-machine interface terminal (fanless embedded all-in-one machine)
[Core Parameters]
Processor: Intel Celeron J1900 quad core 2.0GHz
Memory: Standard 4GB DDR3L, expandable up to 8GB
Storage: mSATA solid-state drive, commonly with a capacity of 120GB
Operating system support: Windows 10 IoT Enterprise or Windows Embedded Standard
Power input: 24V DC (typical power consumption is about 23W)
[Display Parameters]
Screen size: 10.4-inch TFT LCD
Resolution: 800 × 600 pixels (SVGA)
Brightness: Approximately 400 cd/m ²
Touch mode: 5-wire resistive touch screen
Front panel material: aluminum alloy, front panel protection level IP65
[Interface and Communication]
2 Gigabit Ethernet ports
Multiple USB 2.0/USB 3.0 interfaces
1 RS-232/RS-485 serial port
Optional expansion module (S0 series supports additional customized IO)
Mechanical and Environmental Characteristics
Installation method: panel embedded installation
Working temperature: 0 ° C~50 ° C
Size approximately: 150mm × 240mm × 350mm
Weight approximately: 3.8kg
Product details picture:
