ATLAS COPCO 2102-S4-115R Sensor

Product manual:

1、 Product Overview
ATLAS COPCO 2102-S4-115R is a torque/angle sensor component integrated into the Power Focus controller system,
Usually used in conjunction with Tensor S4 series electric tightening tools for industrial grade precision assembly operations.

This model is commonly seen in the Power Focus 2100 series controllers,
Used for low to medium complexity tightening applications, it is an important component of the Atlas Copco industrial fastening system.

2、 Functional characteristics
Torque and angle detection: Real time capture and feedback of torque and angle data, supporting closed-loop control.

High compatibility: Highly compatible with Tensor S4 series tools, suitable for multiple workstations.

High control accuracy: With the cooperation of the controller, a stable and consistent fastening process can be achieved.

Suitable for AC 115V power supply system (115R represents 115V version).

3、 Main parameters (typical configuration)
Model: 2102-S4-115R

Adaptation tool: Tensor S4 electric servo tool

Controller platform: Power Focus 2101 or Power Focus 2100 series

Power supply requirement: 115V AC single-phase

Functional modules: including tightening data sensors, signal processing modules, basic I/O interfaces, etc

4、 Application Fields
Automobile industry

Used for assembly of low and medium torque parts such as seats, door locks, interior, and suspension components

Meet the requirements of process monitoring and traceability

Home appliances and electronics manufacturing

Precision screw tightening, such as motor housing, electrical control box, panel fixing, etc

Light machinery assembly

Tightening tasks for enclosures or connection parts of general machinery, motors, and pumps

Maintenance and tool calibration scenarios

Used for torque verification and data comparison in conjunction with testing tools

Product details picture:

2102-S4-115R
