ATLAS COPCO PF-3110S-S4/7 Torque Tool Controller

Product manual:

1、 Product Overview
ATLAS COPCO PF-3110S-S4/7 is a specialized tightening controller in the Power Focus 3000 series,
Specially designed to complement Tensor S4 and S7 electric torque tools.
This controller supports multiple industrial communication protocols and has precise tightening process control, data recording, and process traceability functions.

2、 Technical parameters (partial characteristics)
Controller model: PF-3110S-S4/7 (part number: 8433 1700 05)

Supporting tools: Atlas Copco Tensor S4, Tensor S7 series

Tightening method: torque control, angle control, combination control

Communication interfaces: Ethernet, RS-232, RS-485 (specific models supported)

Data function: traceable data storage, batch statistics, fault alarm

Software support: Compatible with ToolsTalk and other process management software

Power requirement: Typically powered by 24V DC (depending on actual configuration)

3、 Application Fields
automobile making

Key tightening for chassis, powertrain, suspension and other components

Multi step tightening sequence control and process consistency assurance

EADS

Precise component connection ensures torque consistency and safety

The process is fully traceable and meets the requirements of quality management

Assembly of electronic and electrical equipment

Standardized fastening operations for control boards, terminal boxes, and other products

Avoid excessive twisting and damage to precision components

General industrial machinery

Tightening high-strength bolts on key parts such as pump body, valves, hydraulic system, etc

Support a large amount of data feedback and fault analysis

Construction Machinery and Heavy Industry

High precision control of large fasteners in multifunctional assembly stations

Product details picture:

PF-3110S-S4/7
