Atlas Copco PF3109-C-DN-HW Drive Unit Controller

Product manual:

1、 Product Overview
Atlas Copco PF3109-C-DN-HW
It is an intelligent power tool drive controller for the medium to high torque range in the Power Focus 3100 series.
It is used to control the Atlas Copco Tensor series electric tightening tools, achieving precise torque and angle control,
Supporting industrial bus communication and highly integrated tightening program management, it is widely used in automated assembly lines that require high quality tightening of connectors.

Interpretation of Model Meaning:
PF3109: PF3100 series medium to high power models, suitable for high load tightening tools

C: Standard control version, suitable for the vast majority of industrial control applications

DN: Integrated DeviceNet communication interface

HW: Hardware Version

2、 Core technical parameters
Project Specification Description
Support tools such as Tensor ST, STR, SL, EBL, ETX series and other high torque tools
Power input AC 100-240V, 50/60Hz, single-phase
Control functions include torque control, angle control, angle monitoring, multi-stage tightening control
Maximum number of programs ≥ 255 independently configurable tightening programs
Communication methods: DeviceNet (integrated), Ethernet, serial port, digital I/O
Tighten the support for real-time data collection, curve storage, local and network uploading
Installation method: DIN rail installation or panel embedded installation inside the control cabinet

3、 Typical application areas
1. Assembly of the entire car and its components
Tightening of key bolts for engine, chassis, suspension, electric drive structural components, etc

Workstation level controller, combined with main control PLC/MES to achieve multi workstation collaborative control

2. New energy vehicles and power battery industry
High precision torque assembly of battery casing, module assembly, and electronic control unit

Support data integration with MES platform to achieve product level traceability management

3. Intelligent automated tightening system
Collaborate with robots to achieve automatic bolt recognition and program calling

Tightening action and position information linkage control to improve job consistency

Product details picture:

PF3109-C-DN-HW
