Atlas Copco PF3109-C-PB-HW Torque Tool Controller

Brand:Atlas Copco
Model:PF3109-C-PB-HW
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Atlas Copco PF3109-C-PB-HW Torque Tool Controller

Product manual:

product name
Atlas Copco PF3109-C-PB-HW Torque Tool Controller

Product Introduction
PF3109-C-PB-HW is an intelligent tightening controller in the Atlas Copco Power Focus 3100 series, mainly used to drive Tensor series electric tightening tools.

C represents standard control function

PB indicates support for PROFIBUS communication interface

HW represents standard hardware configuration, stable and reliable

This controller can achieve high-precision torque and angle control and is suitable for multi-stage bolt tightening processes,
Support integration with factory automation systems.

Main application areas

Automotive final assembly and component assembly
High precision bolt tightening for key parts such as chassis, engine, transmission system, and body structure, ensuring tightening quality and consistency.

New energy vehicles and battery manufacturing
Suitable for precision connections of battery modules, electronic control housings, and other components, supporting MES system integration to achieve data traceability and error prevention management.

Industrial automation tightening workstation
Used in conjunction with robots or automated assembly lines, it supports multi program switching and complex process control to improve assembly efficiency.

Rail transit and engineering machinery manufacturing
Suitable for torque control tasks of large and medium-sized structural components, ensuring connection reliability and meeting high-strength industrial requirements.

Assembly of household appliances and electronic products
Can be used for precision bolt connections in low torque scenarios, improving product consistency and assembly reliability.

Product Features

Multi parameter programmable control of torque/angle/time, etc

Built in PROFIBUS interface for easy integration with systems such as Siemens

Compatible with multiple Atlas Copco power tool models

Support multi-stage tightening strategy and multi-channel program management

Provide process data recording and quality traceability capability

Compact structure, suitable for integrated installation in control cabinets or on-site equipment
