Atlas Copco PF3109GPBHW processor

Brand:Atlas Copco
Model: PF3109GPBHW
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Atlas Copco PF3109GPBHW processor

Product manual:

product name
Atlas Copco PF3109-G-PB-HW processor

Product Introduction
PF3109-G-PB-HW is a high-performance intelligent tightening controller in the Atlas Copco Power Focus 3100 series,
Specially designed to drive high torque electric tools in the Tensor series.

G represents the graphical interface version, which supports local operations and visual display

PB stands for built-in PROFIBUS communication interface, compatible with automation systems such as Siemens

HW represents standard hardware configuration

This processor can be used for complex tightening tasks such as multi-stage torque control, angle control, and torque monitoring,
And have the ability to collect data and integrate industrial systems.

Main application areas

Assembly of automobiles and their components
Used for high-precision tightening of bolts in engines, chassis, structural components, etc., meeting the requirements of assembly line automation and process consistency.

Manufacturing of new energy vehicles and batteries
Used for bolt connection control of key parts such as battery packs, electronic control modules, and housing structures, ensuring controllable and traceable tightening quality.

Industrial Robot Tightening Workstation
Integrate with robot systems, perform automated assembly tasks, support multi program calling and industrial network collaboration.

Rail Transit and Engineering Machinery Manufacturing
Suitable for medium to high torque bolt tightening processes that require high connection strength and stability.

Manufacturing of household appliances and electrical equipment
It can meet the flexible assembly needs of multiple varieties, achieve rapid changeover and stable tightening process control.

Product Features

Multi stage torque and angle control capability

Supports PROFIBUS interface for easy communication with the main control system

The graphical interface is easy to set up and maintain on site

Can collect tightening process data and upload it to MES or SCADA system

Compatible with multiple electric tightening tools such as Tensor ST, STR, EBL, etc
