Atlas Copco PF4000 Graphics Controller

Brand:Atlas Copco
Model:PF4000
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Atlas Copco PF4000 Graphics Controller

Product manual:

1、 Product Overview
The Atlas Copco PF4000 graphics controller is part of the PF4000 series intelligent tightening system,
It is used to drive and control Tensor series electric tightening tools,
Provide high-precision tightening control, graphical program settings, data traceability, and system integration capabilities.

2、 Main functional features

Advanced program control: supports torque, angle, multi-stage, and composite control strategies

Process monitoring: Real time display of tightening curves, torque values, status codes, error warnings, etc

Tool compatibility: Supports the full range of Atlas Copco tools such as Tensor ST, STR, ETX, EBL, etc

Supporting communication protocols: PROFINET, EtherNet/IP, DeviceNet, Modbus TCP, I/O, etc

Data processing and traceability: Tighten the local storage of data and upload it to MES/QMS system

Multi station control capability: supports multiple focal points, program switching, and product recognition

3、 Typical application areas
Automobile assembly

Vehicle tightening station (powertrain, chassis system, body structural components)

Modular assembly areas such as car doors, dashboard, seats, etc

Integrate with MES system to achieve process switching, VIN binding, and graphic operation guidance

New Energy and Battery Manufacturing

Connection between battery module housing and electric drive control module

High precision electric tightening scenarios that require data traceability and process visualization

Industrial automated assembly line

Collaborate with robot systems to perform dynamic program switching

Using graphical interfaces to improve process response speed in multi station and variable batch production lines

Engineering machinery, rail transit

Control of staged tightening process for high torque bolts

Ensure connection reliability in high vibration and high load environments

High end electrical appliance manufacturing

Flexible tightening station for white goods and electronic control equipment

In scenarios where high assembly quality is required and there are many operators, graphic controllers are convenient for quick training and operation
