ATLAS COPCO TC52P-N servo driver

Product manual:

1、 Product Overview
TC52P-N is an industrial grade servo drive control unit in the Atlas Copco TC5000 series,
Mainly used to drive and control Atlas Copco's multi axis servo tightening tool. In this model:

TC52 represents its series (high-end control platform, supporting multi-channel servo control)

P indicates that the communication interface type is PROFIBUS

N usually represents the basic configuration or standard single channel control module

As an important component of servo tightening systems, this product is widely used in industrial applications that require high precision in torque control and data traceability.

2、 Main functions and technical parameters
Product Type: Servo Drive Control Unit

Communication protocol: PROFIBUS-DP (supports integration with mainstream PLCs such as Siemens)

Control ability:

Three dimensional closed-loop control of torque, angle, speed, etc

Support multiple tightening programs (such as pre tightening, main tightening, and testing)

Process curve recording and alarm analysis

Compatible systems: Compatible with Power MACS, Tightening Software, Atlas Copco servo tools

Input/output:

Multiple digital/analog I/O interfaces

Integrate with HMI or MES systems

Safety and Protection:

Equipped with over temperature, overload, short circuit, and out of step protection

Redundant power supply connection enhances system stability

Installation method: Modular integration inside the control cabinet, DIN rail or fixed plate installation

3、 Typical application areas
1. Automobile manufacturing
Multi channel tightening process control for engine, chassis, axles, seats, etc

Collaborate with robots to achieve synchronous multi axis tightening tasks

2. Construction Machinery and Rail Transit
Applied to assembling high torque and high reliability components

Implement full process management and traceability of tightening data

3. Electrical appliances and precision manufacturing
Support flexible assembly and quick switching of multiple products

Prevent poor tightening and improve product consistency

4. Aerospace
Meet high standards and high consistency fastening requirements

Support traceability and digital analysis of the assembly process

Product details picture:

TC52P-N
