ATLAS COPCO TC52S-N-TT Tightening System Controller

Product manual:

Brief introduction
ATLAS COPCO TC52S-N-TT is an industrial grade servo controller,
Belonging to the Atlas Copco Power MACS/TC5000 series, designed specifically for controlling complex, multi-channel tightening systems.
It has excellent torque, angle, and process control capabilities, and is widely used in automated assembly production lines,
Especially suitable for applications that require high quality, consistency, and traceability.

2、 Overview of Core Functions and Parameters
Product model: TC52S-N-TT

Type: Servo tightening controller/Multi channel tightening system controller

Control capability: Supports single channel or multi-channel servo tool control (synchronous or asynchronous)

Control methods: closed-loop torque control, angle control, time control, combined process control

Communication interface:

Supports industrial buses such as PROFINET, EtherNet/IP, CANopen, Modbus TCP, etc

Can connect to host control systems (such as PLC, MES)

Functional modules:

Multi process stage setting

Tightening curve monitoring

Data recording and process tracing

Tightening program switching, tool identification, fault self diagnosis

Installation method: Modular installation, can be embedded in the control cabinet or installed independently

3、 Typical application areas
automotive industry

engine assembly

Suspension system, chassis connection

Synchronized tightening of body structural components

Machinery and equipment manufacturing

Assembly scenarios with high torque or synchronous tightening

Hydraulic system, fastening of machine tool structural components

Aerospace and Rail Transit

Suitable for fastening operations with multiple verifications and high safety standards

Home appliances and electronic assembly

High precision small torque tightening ensures assembly consistency

Product details picture:

TC52S-N-TT
