ATLAS COPCO TC52SM Controller Unit
Brand:Atlas Copco
Model: TC52SM
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
ATLAS COPCO TC52SM Controller Unit
Product manual:
1、 Product Overview
TC52SM is a multi-channel servo control unit in the TC5000 series controller launched by Atlas Copco,
Usually used in conjunction with Power MACS 4000 or multi axis tightening systems.
This controller is designed specifically for industrial assembly scenarios that require high-precision, multi axis synchronous control,
It has a compact structure, high-speed data processing capability, and powerful real-time communication capability.
SM "generally represents" Servo Module ", which is used to centrally control multiple servo tightening channels.
2、 Product Features and Technical Parameters
Model: TC52SM
Type: Servo drive controller unit (multi axis control)
Main purpose: Centralized drive and control of multi-channel electric fastening tools
Control support:
High precision torque/angle/speed control
Multi channel synchronous control
Real time monitoring of fastening curves
Communication interface: Supports EtherNet/IP, PROFINET, PROFIBUS, etc
Program support: Multiple fastening process programs can be configured for quick switching
Electrical protection: equipped with electrical protection such as short circuit, over temperature, overload, etc
Installation method: Standard control cabinet integration, modular structure
3、 Application Fields
1. Automobile manufacturing
Synchronized tightening of multiple bolts such as engine, axle, suspension system, etc
The core control unit of high tempo assembly line
Adapt to Atlas Copco multi axis system and custom fixtures
2. Assembly of large industrial equipment
Suitable for fastening structural components of heavy machinery equipment, machine tools, etc
Support high torque and long stroke synchronous control
3. Home appliances and electronic manufacturing
Support flexible switching between multiple workstations
Improve assembly accuracy and efficiency
4. Rail Transit and Aerospace
Bolt connections for high consistency requirements
Having the ability to trace data throughout the entire process, in compliance with the quality management system
Product details picture:
TC52SM
