BENTLY 3500/22 288055-01 Transient Data Interface

Brand:BENTLY
Model:3500/22 288055-01
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

BENTLY 3500/22 288055-01 Transient Data Interface

Product manual:

product name
Brand: Bently Nevada

Module model: 3500/22

Part number: 288055-01

Module type: Transient Data Interface

Module Overview
BENTLY 3500/22 (PN: 288055-01) Transient Data Interface Module is a part of the 3500 series mechanical protection system, used to achieve high-resolution data exchange between the system and external analysis tools.

The main function of this module is to transmit high-speed transient data (such as vibration waveforms, impact events, start/stop data, etc.) to Bently's data acquisition and analysis platform, such as System 1, for engineering personnel to perform fault diagnosis and trend analysis.

major function
Real time capture and transmission of high-resolution transient signal data

Provide dynamic behavior monitoring data for key rotating machinery

As a data bridge between the 3500 system and system analysis software

Support event recording and analysis of startup/shutdown processes

Seamless integration with System 1 platform for condition monitoring and predictive maintenance

Technical Parameter
Data types: raw waveform, trajectory data, impulse response, critical operational events

Sampling capability: High frequency transient acquisition capability (specific frequency depends on the installed front-end sensors and system configuration)

Interface type:

Front end connected to 3500 rack backplane (data bus)

Backend provides communication ports (for connecting with servers and System 1)

Support channels: Supports synchronous data collection for up to multiple dynamic channels

Installation location: Installed in the 3500 series rack, occupying standard module slots

Firmware support: requires matching version of configuration software and System 1 data platform
