BERGER LAHR TLC411F Stepper Motor Control Driver
Brand:BERGER LAHR
Model: TLC411F
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
BERGER LAHR TLC411F Stepper Motor Control Driver
Product manual:
1、 Product Overview
TLC411F is a universal stepper motor driver launched by BERGER LAHR (now a brand under Schneider Electric), designed for precision motion control systems. It can drive two-phase or hybrid stepper motors and is widely used in fields such as automation, machine tool control, precision conveying, semiconductor equipment, and industrial detection systems, providing precise position control and efficient torque output.
2、 Technical parameters
Input power supply:
Voltage: Approximately 115/230 VAC (optional)
Frequency: 50/60 Hz
Output current:
Maximum phase current: adjustable, generally ranging from 1A to 4.5A
Current control method: constant current PWM modulation
Applicable motor types:
Two phase or hybrid stepper motor
Step control:
Supports full step, half step, and micro step (typical values 1/2, 1/4, 1/8)
The step resolution setting is flexible and can be set through dialing or software
Interface type:
Input: Pulse (STEP), Direction (DIR) signal interface
Control logic: TTL/differential signal compatible
Equipped with alarm output, enable signal, fault diagnosis interface, etc
Protection function:
Overvoltage, overcurrent, overheating, short circuit protection
Fault LED indicator for easy troubleshooting
Installation method:
Standard DIN rail or screw installation
Cooling method:
Air cooling or natural convection, depending on the installation environment
Product details picture:
TLC411F
