CB801 3BSE042245R1 processor module

Model: CB801 3BSE042245R1
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

CB801 3BSE042245R1 processor module

Product manual:

CB801 3BSE042245R1 is a PROFIBUS-DP slave communication module designed by ABB specifically for the Panel 800 human-machine interface system, used for high-speed data exchange between HMI and fieldbus devices.
Core Features
Positioned as a PROFIBUS-DP slave expansion module, compatible with ABB Panel 800 series
Communication speed ranging from 9.6 kbps to 12 Mbps, supporting high-speed real-time data transmission
Wide temperature range: -20 ℃ to+70 ℃, suitable for harsh industrial environments
Industrial grade anti vibration design, M12 interface, vibration resistance up to 5g
Power supply: 12-24 V DC ± 10%, suitable for industrial DC power supply
Size: 121.5 × 49.5 × 153 mm, weight 0.2 kg, compact and easy to install
Protection level IP20, suitable for installation inside control cabinets
Integrated LED status indicator for quick diagnosis and troubleshooting
Plug and play, seamlessly integrated with Panel 800 system
Supports multi device networking and can access a large number of fieldbus slave stations
Hardware level data verification ensures transmission reliability
Compliant with IEC 61158-2 international standard, strong compatibility
Produced by Swedish factory, CE certified, stable quality
Support hot plugging (partial configuration), easy maintenance
High speed monitoring scenarios suitable for continuous processes and discrete manufacturing
Typical Applications
PROFIBUS-DP communication between Panel 800 HMI and PLC, frequency converter, and instrument
Manufacturing production line: data acquisition and monitoring of robots, servo systems, and IO stations
Energy industry: Real time monitoring of equipment status in power plants and substations
Chemical/Metallurgical: High speed Data Interaction between DCS and Field Instruments
Logistics/Warehousing: HMI Control and Status Feedback of Automated Conveyor Lines
This module is centered around high speed, reliability, and ease of integration, and is the standard communication component for ABB Panel 800 system to connect to PROFIBUS-DP network.
