Control Techniques SK2403 Inverter

Product manual:

Product Overview

The Control Techniques SK2403 frequency converter belongs to the Unidrive SK series and is a high-performance AC variable frequency speed regulation device. This series is known for its compact design, flexible expansion, and high reliability, making it suitable for industrial scenarios that require precise speed and torque control. SK2403 offers multiple control modes, including open-loop vector control and V/F control, to meet different needs from simple fans to complex production lines.

Technical Specifications

Input voltage range: three-phase 380-480V AC

Power level: approximately 11kW (15HP)

Control modes: V/F control, open-loop vector control

Frequency range: 0-550 Hz adjustable

Overload capacity: 150% 60 seconds/180% short-term

Interface configuration: Built in digital and analog I/O, supporting expansion modules (communication, feedback, etc.)

Protection functions: overvoltage, undervoltage, overcurrent, overload, overheating, grounding faults, etc

Application scenarios

Conveyor and handling system: achieve smooth start stop and speed adjustment, reduce mechanical impact.

Fan and pump equipment: Energy saving and consumption reducing through variable frequency speed regulation, improving operational efficiency.

Textile and paper industry: providing precise speed control to ensure production line stability.

Metal processing and woodworking machinery: supports high dynamic response to meet the driving requirements of complex processes.

Food and packaging machinery: Improve flexibility and production efficiency, adapt to multi process automation control.

Product advantages

Compact structure: requires minimal installation space, making it easy to embed into cabinets or equipment.

Stable performance: Designed with high reliability, suitable for long-term continuous operation.

Flexible Expansion: Supports multiple optional modules, such as Profibus, Ethernet, DeviceNet, and other communication interfaces.

Energy saving and efficient: intelligent energy management to reduce operating costs.

Easy to operate: Built in operation keyboard and parameter setting wizard, simplifying the debugging process.

Control Techniques  SK2403 Product details picture:

SK2403

Control Techniques SK2403 product video
