Control Techniques SP2401 Servo Drive

Product manual:

Product Overview

Control Techniques SP2401 is an industrial grade servo drive belonging to the Unidrive SP series. This driver is designed specifically for closed-loop servo motors, providing precise speed, torque, and position control. SP2401 is suitable for high-performance automation equipment, machine tools, packaging machinery, and robot systems, ensuring smooth motion control, fast response, and accurate positioning.

Technical Specifications

Model: SP2401

Type: Servo Drive/AC Servo Drive

Suitable motor: three-phase servo motor

Rated power: approximately 2.4 kW (may vary slightly depending on the specific model configuration)

Input power supply: three-phase 380-480 V AC

Control method:

Closed-loop vector control

Accurate position, speed, and torque control

Feedback interface: Supports encoders (incremental/absolute)

Protection functions: overload, overvoltage, undervoltage, short circuit, over temperature protection

Communication interface: Supports industrial protocols such as Modbus, CANopen, Ethernet/IP, etc

Installation method: Modular design, can be installed in cabinets or racks

Application scenarios

High precision machine tools: CNC machine tool spindle or servo axis drive

Industrial Robots: Joint and Handling Motion Control

Packaging Machinery: High speed Packaging Machines and Sorting Equipment

Textile and printing equipment: production equipment that requires precise motion control

Experiment and R&D: Servo motion control testing and experimental platform

Control Techniques  SP2401 AC Drive  Product details picture:

SP2401

Control Techniques SP2401 AC Drive product video
