COR-3/230R motion control module

Product manual:

Introduction to COR-3/230R Motion Control Module

COR-3/230R is an industrial grade motion control module used for precise position, speed, and torque control of servo or stepper drives in automation systems. It is usually integrated into motion control systems or CNC control cabinets, responsible for converting the motion commands of the upper controller into precise motor drive signals.

Main functions
1. Multi axis motion control

Support multi axis synchronous or independent motion control

Provide closed-loop position, speed, and torque control

Suitable for complex path control and mechanical synchronization operations

2. Signal interface

Input: Receive pulse/direction, analog or digital bus instructions from the controller

Output: Drive servo or stepper motor to achieve precise positioning

Can be connected to encoders or sensors to achieve closed-loop control

3. High precision and high response

Supports high-resolution position control, suitable for precision machinery

Fast response speed, capable of meeting high-speed production or processing requirements

4. Protection and monitoring

Built in overcurrent, overvoltage, overheating, and short circuit protection

Monitor the motor and drive status, provide alarm signals

Improve system security and reliability

Typical Applications

Multi axis motion control of automated production line

Joint control of industrial robots

The spindle and feed axis of CNC machine tools

Packaging machinery, printing machines, and handling systems

Industrial automation equipment that requires high-precision closed-loop control

COR-3/230R Product details picture:

COR-3/230R product video
