DELTA TAU ACC-68E Control Board

Brand:Delta Tau
Model:ACC-68E
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

DELTA TAU ACC-68E Control Board

Product manual:

Delta Tau ACC-68E is a multifunctional motion control interface board designed specifically for Delta Tau's UMAC (Universal Motion and Automation Controller) system,
Mainly used for high-speed and multi axis synchronous control, widely applied in the field of industrial automation.

2、 Main functions
Multi axis control: supports closed-loop control of multi axis servo and stepper motors,
Usually used for complex mechanical motion control systems.

Rich interfaces: integrated analog input/output and digital input/output interfaces,
Adapt to the connection requirements of various sensors and actuators.

Encoder support: Supports high-resolution encoder input,
Including incremental and absolute encoders, suitable for precision positioning applications.

Signal processing: Supports high-speed signal sampling and processing, with powerful real-time motion control capabilities.

Modular design: Can be inserted into UMAC 3U rack for easy expansion and maintenance.

3、 Technical specifications
Installation form: Standard 3U plug-in card, compatible with UMAC system rack.

Power supply requirement: ± 15V power supply is provided by the UMAC main frame backplane.

Axis support: Usually supports dual axis control, and some configurations can support more axes.

Interface type:

Analog input/output (± 10V common)

Digital input/output (TTL/differential compatible)

Encoder input (ABZ signal channel)

Signal sampling frequency: up to tens of kHz, meeting the requirements of high-speed motion control.

Environmental adaptation: Industrial grade temperature range, anti electromagnetic interference design.

4、 Application Fields
CNC
