DPA96A power analyzer

Product manual:

The DPA96A power analyzer is a high-precision industrial electrical measuring instrument used for monitoring, analyzing, and recording electrical parameters of power systems. It is widely used in the fields of power, industrial automation, and scientific research.

Core Features

Multi parameter measurement

It can measure parameters such as voltage, current, power (active, reactive, apparent power), power factor, frequency, and electrical energy.

Supports single-phase, three-phase, and unbalanced load measurement, suitable for complex power grid environments.

High precision and fast response

Built in high-precision sensors and signal processing units ensure accurate and reliable measurement results.

Real time sampling and analysis can capture rapidly changing power parameters.

Data recording and analysis

Built in memory can record historical data and support export analysis.

It can be connected to PC, PLC or SCADA systems through communication interfaces to achieve remote monitoring and analysis.

Alarm and protection functions

Thresholds can be set to trigger alarm outputs when voltage, current, or power are abnormal.

Equipped with overload protection and overvoltage protection functions, it improves the safety of use.

User friendly interface

The panel display is clear and supports graphical interface and numerical display.

Easy to read data and adjust parameters on site.

Typical application scenarios

Industrial power monitoring: monitoring the operation status and load situation of the power system in factories or workshops.

Energy management: used for energy metering, power factor analysis, and energy-saving evaluation.

Research and Testing: Laboratories or R&D departments measure the power characteristics and electrical energy efficiency of equipment.

Power system maintenance: Monitor the operation status of key equipment such as distribution networks, motors, and transformers.

DPA96A Product details picture:

DPA96A product video
