DS200XDSAG1A Relay Output Board

Model: DS200XDSAG1A
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

DS200XDSAG1A Relay Output Board

Product manual:

Product Overview

DS200XDSAG1A is a relay output board in the Mark series engine control system, used to convert digital signals from the controller into relay actions, thereby driving field actuators such as pumps, valves, alarms, indicator lights, etc.

This module plays a core role in signal execution and action control in industrial control and engine management systems, ensuring that system instructions can be reliably transmitted to on-site equipment.

core functionality

Digital quantity control: Convert CPU output signals into relay switch actions to achieve on-site device control.

Multi channel support: It can drive multiple devices simultaneously and achieve multi-channel control.

Status feedback: The module is equipped with indicator lights to display the working status of each channel for easy monitoring.

Safety protection: It has overload and short circuit protection functions to ensure the safety of modules and loads.

Technical Features

Industrial grade relay components, resistant to high-frequency switching and industrial environmental interference.

Modular design, easy to install, disassemble, and maintain.

Supports continuous operation and frequent switching operations, with high reliability.

Seamless compatibility with Mark series CPUs and I/O systems.

Can be used for redundant configuration to improve overall system stability.

Application scenarios
