DSDP170 57160001-ADF pulse counting board

Model: DSDP170 57160001-ADF
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

DSDP170 57160001-ADF pulse counting board

Product manual:

DSDP170   57160001- ADF pulse counting board

This is a pulse counting/speed counting module used in industrial automation systems, commonly found in distributed control systems (DCS) or PLC control racks. It is used to collect and process pulse signals from on-site sensors, encoders, etc., and convert these high-speed pulses into data that can be used by the control system.

Main functions

pulse acquisition
Read pulse signals output from devices such as encoders, speed generators, and photoelectric sensors.

cumulative count
High speed accumulation of input pulses is used to record the position, velocity, or accumulated amount of the rotating axis.

Speed/Position Calculation
Calculate parameters such as motion speed, rotational speed, and displacement based on pulse frequency.

Signal condition processing
Filter and shape the input signal to improve the stability and anti-interference ability of the pulse signal.

system integration
Transmit the pulse counting results to the main controller or processing module for closed-loop control, monitoring, and logical judgment.

Technical Characteristics

high-speed response
Capable of collecting high-frequency pulse signals, suitable for connecting high-speed encoders or speed measuring devices.

Multi channel support
Multiple pulse input channels are provided to process signals from different sensors at the same time.

Industrial-grade design
Anti interference, anti vibration, adaptable to wide temperature environments, suitable for long-term operation in industrial sites.

modular installation
Insert the control frame or rack and use it in conjunction with other modules of the control system.

standards of power supply
Adopting standard industrial power supply (such as+24V DC), compatible with the system power supply architecture.

Status indication and diagnosis
Equipped with indicator lights or diagnostic points for easy maintenance and troubleshooting.
