DSQC313 3HAB22131 Sequence Measurement Module

Model: DSQC313 3HAB22131
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

DSQC313 3HAB22131 Sequence Measurement Module

Product manual:

Introduction to DSQC313 3HAB22131 Sequence Measurement Module

The DSQC313 (3HAB22131) sequence measurement module is a measurement and signal processing module applied in industrial robot systems. It is mainly used to collect position feedback signals and transmit them to the control system. It is an important component to ensure the accuracy of robot operation.

Model: DSQC313
Order number: 3HAB22131 (3HAB2213-1)
Type: Sequence Measurement Module (SMB Board)
Brand: ABB
Functional positioning: Robot measurement and feedback signal processing unit
Core function: Collecting encoder and position signals
Application system: ABB industrial robot control system (such as S4, S4C, S4C+)
Data processing: supports high-precision signal acquisition and processing
Communication method: Communicate with the main controller through an internal bus
Input type: Multi channel measurement signal input
Power requirement: 24V DC industrial power supply
Installation location: Inside the robot control cabinet or measurement unit
Reliability: Industrial grade design, suitable for continuous operation environment
Control function: Improve the accuracy and stability of robot motion control
Compatibility: Compatible with multiple ABB robot models

The DSQC313 3HAB22131 sequence measurement module undertakes critical measurement and feedback tasks in industrial robot systems, and is an important guarantee component for achieving high-precision motion control and stable operation.
