ENTERASYS A4H124-24FX Ethernet Switch
Brand:ENTERASYS
Model: A4H124-24FX
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!
Details
ENTERASYS A4H124-24FX Ethernet Switch
Product manual:
ENTERASYS A4H124-24FX is a full optical port layer 2 Ethernet switch designed specifically for harsh environments and long-distance communication.
Provide 24 100BASE-FX multimode fiber ports, suitable for industrial automation and rail transit
Communication scenarios such as power systems that are sensitive to electromagnetic interference.
This device supports multiple network management protocols and is compatible with various complex network topologies.
Main technical parameters
Parameter Description
Interface type 24 × 100BASE-FX SC multimode fiber optic interface
Upstream port 2 x Gigabit Ethernet RJ45 interface
Switching capacity 8.8 Gbps
Forwarding rate 6.5 Mpps
MAC address table supports 8K entries
VLAN supports IEEE 802.1Q, up to 255 VLANs
QoS supports 802.1p priority scheduling with 4 hardware queues
The management function supports a web management interface SNMP、CLI、Telnet
Security mechanism: Port security, 802.1X, Radius, ACL
Passive cooling design without fan for heat dissipation method
Size (approximately) 44 × 21 × 4.4 cm, 1U standard rack mounted
Power input 100-240V AC, 50/60 Hz
Working temperature range: 0 ° C to 50 ° C (commercial grade environment)
Product Features
Full optical port configuration: 24 SC fiber ports, suitable for long-distance and anti-interference application scenarios
Silent operation: adopting fanless design, suitable for low-noise environments such as computer rooms, control rooms, and office areas
High reliability: supports spanning trees, link aggregation, VLAN isolation, and enhances network redundancy capabilities
Remote management support: Provides remote configuration methods such as Web UI, Telnet, SNMP v1/v2 c/v3, RMON, etc
Security control: Implement network boundary protection through port security, user authentication, and access control lists (ACLs)
Typical application areas
Smart grid and substation communication
Metro, railway and other rail transit monitoring systems
Industrial control system (PLC, DCS communication)
Long distance fiber optic access to campus network or government enterprise park
Data center fiber optic access aggregation node
