ER-JD7200D CNC motor encoder

Product manual:

OKUMA ER-JD7200D is a servo/servo motor encoder used in OKUMA CNC systems, mainly used to provide feedback on motor shaft position and speed, achieving high-precision closed-loop control. Here is its main information and application overview:

Basic Information

Type: Servo motor encoder

Model: ER-JD7200D

Manufacturer: OKUMA

Purpose: To provide position and speed feedback for servo motors, achieving precise motion control

Interface type: incremental or absolute encoder (depending on system configuration)

Installation: directly fixed on the motor shaft, outputting signals as the motor rotates

Features and Functions

High resolution position feedback ensures precise positioning of the CNC system

Support speed feedback for closed-loop speed control

Can be directly integrated with Okuma servo drives and CNC control systems

Fast response speed, suitable for high-speed machining and precision positioning

Provide reliable mechanical and electrical interfaces to ensure long-term stable operation

Applicable scenarios

The servo system of Okuma CNC machine tools

Automated machining centers and multi axis CNC systems

Industrial applications that require high-precision position control and high-speed motion control

Multi axis linkage and synchronous machining scenarios

ER-JD7200D Product details picture:

ER-JD7200D product video
