ETHERWAN EL100T Media Converter

Brand:ETHERWAN
Model:EL100T
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ETHERWAN EL100T Media Converter

Product manual:

ETHERWAN EL100T is an industrial grade Ethernet media converter launched by EtherWAN Systems,
Specially designed for efficient conversion between copper cables and fiber optic networks in harsh environments.

2、 Main features
Copper fiber conversion function: realizing media conversion between 10/100BASE-TX and 100BASE-FX

Plug and play: No additional software required, ready to use upon startup, simplifying deployment

Full duplex/half duplex adaptive: automatically recognizes and matches connection rate and duplex mode

Link Failure Propagation (LFP) mechanism: enhances network reliability and quickly responds to link interruptions

Industrial grade design: Supports wide temperature operation, metal casing, with anti-interference capability

DIN rail and wall mounted installation options: compatible with various deployment methods of industrial control cabinets

3、 Technical specifications
Project Description
Ethernet port 1 RJ45 interface, 10/100BASE-TX, adaptive MDI/MDI-X
1 100BASE-FX fiber port (SC/ST/LC optional), multi-mode or single-mode optional
Fiber optic transmission distance: multimode: maximum 2 km, single-mode: maximum 20/40/60 km (different models)
Working mode full/half duplex automatic negotiation
Power input 12~48VDC, redundant dual power input
Power consumption of approximately 2.5W (typical)
Link Fault Propagation (LFP) support
Anti surge protection 15KV ESD protection, 2KV power surge protection
Working temperature -10 ° C~+60 ° C (standard model) or -40 ° C~+75 ° C (extended model)
Installation method: DIN rail or wall mounted installation
Shell material: metal industrial grade shell
Size approximately 30 × 70 × 95 mm
Weight approximately 0.3 kg

4、 Typical applications
Industrial Ethernet long-distance fiber optic communication

Factory Automation and Data Acquisition System

Intelligent Transportation Systems (ITS)

Electricity and Energy Monitoring Network

Video surveillance system (advantages of fiber optic lightning protection)

Data transmission in the petrochemical and oil and gas industries
