ETT-VGA-0045 Operator Interface Panel

Model: ETT-VGA-0045
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

ETT-VGA-0045 Operator Interface Panel

Product manual:

Product Overview

ETT-VGA-0045 is an industrial Operator Interface Panel (OIP) used for interacting with equipment, PLCs, or DCS systems in industrial automation systems. It provides a visual interface for operators, displaying real-time data, alarm information, and allowing operators to input control commands.

This panel typically uses a VGA display interface, supporting graphical display and touch operation (depending on the model).

core functionality

Real time data display: displays sensor measurements, process parameters, and system status.

Alarm and event display: Timely display process abnormalities or alarm information to improve on-site response speed.

Operation control: Send control instructions through buttons or touch interface to achieve local device operation.

Human computer interaction interface: supports menus, charts, trend curves, and parameter adjustments to improve operational efficiency.

Communication interface: It can be connected to PLC, DCS or controller modules and supports industrial communication protocols.

Technical specifications (typical)

Display interface: VGA, standard resolution (such as 640 × 480 or 800 × 600, depending on the model)

Input method: button, knob or touch screen (depending on the model)

Power supply: DC or AC industrial power supply, in accordance with panel specifications

Working temperature: 0 ℃~50 ℃ (general industrial environment)

Installation method: panel embedded installation or bracket installation

Communication protocol: can communicate with the control system through standard industrial bus or serial interface

Application scenarios

The human-machine interface of industrial automation production line

Factory equipment monitoring and process data visualization

Local control station of PLC or DCS system

Industrial alarm management and operation log display

summary

ETT-VGA-0045 is an industrial operator interface panel that provides real-time data visualization, alarm display, and local operation functions. It is the core device for human-machine interaction in automation control systems, enabling operators to conveniently and intuitively monitor process parameters and operate equipment.
