EVS9321-EP servo driven inverter

Model:EVS9321-EP
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

EVS9321-EP servo driven inverter

Product manual:

Introduction to LENZE EVS9321-EP Servo Drive Inverter

The LENZE EVS9321-EP is a compact single axis model in the 9300 series servo drives, designed specifically for high-performance position control, speed control, and torque control. This series is widely used in the automation industry due to its strong reliability, flexible debugging, and support for a wide range of servo and asynchronous motors.

EVS9321-EP is suitable for small and medium power applications, with rich expansion interfaces, and is a typical driving solution for packaging machinery, conveyor systems, and high-speed station equipment.

Key Features

Integration of three control modes
Supports servo control, vector control, and U/f curve control, adapting to various mechanical transmission requirements.

Can drive multiple types of motors
Including synchronous servo motors, asynchronous motors, and some permanent magnet motors, suitable for equipment modification or hybrid drive systems.

EP version has strong scalability
The "EP" model usually comes with specific communication and expansion configurations, which can support a wider range of system integration requirements.

Convenient parameter debugging
Combined with Lenze Global Drive Control (GDC) software, motor identification, debugging, and diagnosis can be quickly completed.

Typical Technical Parameters (9300 Series 9321 Grade Reference)

9321 belongs to the smaller power range model. If you need accurate rated current and power, I can help you further confirm.

Input power supply: three-phase 400V level

Power level: usually in the range of 0.75 to 1.5 kW

Control mode: servo vector control/speed control/V/f control

Encoder interface: supports incremental encoders, rotary encoders, etc. (depending on configuration)

Communication interface: EP version can choose Lenze exclusive fieldbus or expansion module

Protection functions: overcurrent, short circuit, over temperature, under voltage, encoder fault, overload protection

Cooling method: natural air cooling or external air cooling

Environmental temperature: generally 0...+40 ° C (full load)
