EVS9322-EP servo driver

Model:EVS9322-EP
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

EVS9322-EP servo driver

Product manual:

Introduction to Lenze EVS9322-EP servo drive

EVS9322-EP is a servo positioning driver belonging to the Lenze 9300 series, used to achieve three control modes: position, speed, and torque. This model is suitable for small and medium power servo systems, especially industrial equipment with high requirements for accuracy and dynamic response.

Main Performance and Characteristics

Complete positioning control function
Built in servo positioning controller, which can directly execute action control logic such as point positioning, following, interpolation, etc.

High dynamic response
The driver supports fast current loop and speed loop regulation, which can significantly improve system response speed and stability.

Support multiple encoder feedback
Compatible with common incremental encoders, absolute value encoders, etc., it can achieve high-precision closed-loop control.

Scalable communication interface
Fieldbus modules can be added according to system requirements for integration with PLCs and motion controllers.

Multiple protection functions
It has the ability to protect against overcurrent, overheating, overvoltage, grounding faults, and motor stalling.

Rated parameter range (typical configuration of EVS9322-EP)

Input power supply: three-phase 400-480 V AC

Rated output power: approximately 0.75 kW

Rated output current: approximately 2.5 A

Operating frequency range: 0-100 Hz (depending on application settings)

Cooling method: natural heat dissipation/air duct heat dissipation (installed inside the control cabinet)

Protection level: IP20

Installation method: panel installation, suitable for internal layout of control cabinets

Applicable scenarios

Packaging, assembly, and electronic manufacturing equipment
