EXTREME 220-48P-10GE4 Managed Switch

Brand: Extreme Networks
Model: 220-48P-10GE4
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Extreme Networks 220-48P-10GE4 Managed Switch

Product manual:

Features of Extreme 220-48P-10GE4 Managed Switch Product

Product Introduction
Extreme 220-48P-10GE4 is a high-performance hosted Layer 3 switch in the Extreme Networks 210/220 series, suitable for small and medium-sized enterprises and branch offices. It provides high-density gigabit ports and high-speed 10GbE uplink interfaces, supports PoE+functionality, and meets the needs of office environments, data centers, and core networks.

Main Features

Upstream interface: 4 10GBASE-X SFP+fiber ports for high-speed links or network stacking.

Management interface: 1 10/100BASE-T management port and 1 serial console port, supporting remote and local management.

Performance indicators: Switching capacity of approximately 176 Gbps, forwarding rate of approximately 130.9 Mpps, and 16000 MAC address tables.

Stacking function: Supports stacking multiple switches into a single logical device for centralized management.

Power and Heat Dissipation: Built in 485W AC power module, supports hot swapping and redundant configuration, with a maximum power consumption of approximately 485W and heat dissipation of approximately 392 BTU/h under full PoE load.

Size and Installation: Designed with a 1U rack, the dimensions are approximately 44.1 cm x 25.4 cm x 4.4 cm, and the weight is approximately 4.5 kg.

Network function: Supports Layer 3 static routing and RIP, providing VLAN, link aggregation, spanning tree protocol, ACL and other functions.

Management function: Supports Extreme Management system to achieve centralized management and configuration.

Application scenarios

Enterprise network access layer provides stable connectivity for office areas

Branch network deployment, supporting remote management

Deployment of IP cameras and wireless AP power supply

Small data center core exchange

High performance network aggregation, utilizing 10GbE upstream ports to enhance bandwidth

Precautions for use

Confirm whether the PoE power meets the requirements of all access terminals

Plan links and redundancy strategies before stacking configurations
