Extreme Networks D2G124-12P Management Switch

Product manual:

1、 Product Overview

Model Name: Extreme Networks D2G124-12P (also known as D2 12 Port PoE Management Switch)

Device type: Managed/PoE enabled desktop/desktop/small aggregation switch

Positioning: Used for small office environments and workgroup access layers, suitable for providing gigabit access and PoE power supply functions

2、 Ports and interfaces

Ethernet ports: 12 10/100/1000 Mbps RJ-45 ports, supporting PoE (according to IEEE 802.3af)

Upstream/fiber optic interface: 2 shared SFP combination ports (i.e. these ports can be used as electrical or optical ports)

Management/Control Interface: Supports Command Line Interface (CLI), Web Management Interface, SSH/SNMP Management, etc

Redundant power supply/external module: supports external redundant power supply modules (or external power bricks) to enhance reliability

3、 Performance and Capacity

Switching capacity: 24 Gbps

Packet forwarding rate: approximately 17.86 Mpps

MAC Address Table: Supports approximately 16000 addresses

QoS/Traffic Control: Supports L2/L3/L4 traffic classification, priority queues ACL、 Flow control, port mirroring, etc

Network protocol support: VLAN, STP/RSTP/MSTP, multicast IGMP Snooping, Link Aggregation (LACP)

Security features: Supports IEEE 802.1X port authentication, MAC authentication, ACL access control, Radius, SSL/SSH security management, etc

4、 Physical/power/environmental specifications

Size/Appearance: Designed for desktop/desktop devices, can also be installed in a rack (with hanging accessories)

Weight: Approximately 1.8 kg

Power input: AC input (100-240V), supports redundant power modules/individual power bricks

Power consumption: Approximately 130W (including PoE load) under typical operating conditions

Working temperature: 0 ° C to 50 ° C

Humidity/Protection: Humidity support 5% to 95% (no condensation)

Extreme Networks D2G124-12P Product details picture:

D2G124-12P

Extreme Networks D2G124-12P product video
