Extreme EC4800A78-E6 Switch

Brand: Extreme Networks
Model:EC4800A78-E6
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Extreme Networks EC4800A78-E6 Switch

Product manual:

Extreme EC4800A78-E6 Switch Product Features

Product Introduction
The Extreme EC4800A78-E6 is a high-performance switch in the Extreme Networks VSP 4850GTS series, designed specifically for enterprise and campus networks, supporting Layer 3 routing capabilities and suitable for high-density access and aggregation layer deployments.

Main Features

Port configuration: 48 10/100/1000BASE-T RJ45 ports, 2 Combo 1G (RJ45/SFP) ports, 2 10G SFP+uplink ports.

Management interface: 1 RJ45 console port and 1 USB management port.

Performance indicators: Switching capacity of approximately 184 Gbps, forwarding rate of approximately 102 Mpps, MAC address table capacity of 32000 entries, system CPU frequency of 1.2 GHz, and 2GB DRAM.

Power and heat dissipation: Equipped with one 300W replaceable AC power supply, the maximum power consumption is about 300W, and the maximum heat dissipation is about 1024 BTU/h.

Size and Installation: Designed with a 1U rack, the dimensions are approximately 44.5 cm x 30.5 cm x 4.4 cm, and the weight is approximately 7.7 kg.

Network function: Supports Layer 3 static routing and RIP, with VLAN, link aggregation, spanning tree protocol, ACL and other functions.

Management function: Compatible with Extreme Management system, enabling centralized management and configuration.

Application scenarios

Enterprise access layer provides stable connectivity for office areas

Branch network deployment

Deployment of power supply for IP cameras and wireless access points

Small data center core or aggregation exchange

High performance network aggregation, achieving high-speed data transmission through 10GbE uplink

Precautions for use

Confirm that the network design and bandwidth meet the access requirements

Regularly upgrade firmware to ensure performance and security
