Extreme Networks VIM1-10G8X Controller Module

Product manual:

1、 Product Introduction

VIM1-10G8X is a Versatile Interface Module launched by Extreme Networks, mainly used to expand the high-speed uplink capability of switches. This module can provide multiple 10G optical ports, providing higher bandwidth and flexible connection methods for the core layer of data centers or campus networks.

2、 Main functions

Expand 8 SFP+10G optical ports for host devices;

Support stacked connections (Summit Stack function) to achieve unified management of multiple switches;

Provide high bandwidth uplink or aggregation ports for server and core switch interconnection;

Support module hot plugging without interrupting the overall operation of the machine;

Operates in conjunction with the host system and is controlled by the switch control board.

3、 Technical specifications

Model: VIM1-10G8X

Interface type: 8 SFP+fiber optic interfaces

Speed: 10Gbps (per port)

Aggregate bandwidth: maximum 80Gbps (8 × 10G)

Support stacking: SummitStack function can be implemented through module ports

Compatible devices: Suitable for Extreme Networks X650, X670 series and other switches that support VIM slots

Power consumption: approximately 25-30 watts (slightly different depending on configuration)

Dimensions: Approximately 4.3 cm in height, 13.2 cm in width, and 25 cm in depth

Weight: Approximately 0.9 kg

Installation method: slot type modular structure, supporting hot plugging

Cooling method: relying on the air duct of the whole machine for cooling

Extreme Networks VIM1-10G8X Product details picture:

VIM1-10G8X

Extreme Networks VIM1-10G8X product video
