Extreme Networks X590-24X-1Q-2C Port Switch

Brand: Extreme Networks
Model:X590-24X-1Q-2C
Product status: New/used
Shipping place: Xiamen, China
Warranty: 365 days
Structural form: Other (specific form may vary depending on application)
Please contact Yvonne for quotation, thank you!

Details

Extreme Networks X590-24X-1Q-2C Port Switch

Product manual:

Extreme Networks X590-24X-1Q-2C Switch

1、 Product Introduction
Extreme Networks X590-24X-1Q-2C is a high-performance 24 port Gigabit/10 Gigabit Ethernet switch,
Specially designed for enterprise networks and data centers, providing flexible connectivity options and powerful management capabilities,
Meet the demands of modern networks for high-density access and high-speed data transmission.

2、 Main specifications

Port configuration:

24 10/100/1000BASE-T RJ45 ports

1 10Gb/40Gb QSFP+upstream port

Two 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 upstream ports

1 10/100/1000BASE-T management port

1 serial console port

Switching capacity: 880 Gbps

Forwarding rate: 714 Mpps

Memory configuration:

2 GB DDR3 ECC memory

4 GB eMMC flash memory

Power requirements:

Supports 770W AC or 1100W DC power modules (modular design)

Fan module: 4 hot swappable fan modules

Size: 44.1 cm (W) x 48.8 cm (D) x 4.35 cm (H)

Weight: Approximately 6.6 kg

3、 Key characteristics

High density port configuration: Provides 24 10/100/1000BASE-T RJ45 ports,
Meet the access layer requirements of enterprise networks.

High speed uplink: supports 1 10Gb/40Gb QSFP+uplink port and 2 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 uplink ports,
Adapt to different network topologies and bandwidth requirements.

High performance switching capability: with a switching capacity of 880 Gbps and a forwarding rate of 714 Mpps,
Ensure high-speed data transmission.

Flexible power and fan configuration: Supports modular power and fan modules, providing redundancy and high availability.

Intelligent management function: Running the ExtremeXOS operating system,
Support Layer 2/Layer 3 switching, VLAN, QoS, ACL, VXLAN and other functions to meet the needs of complex network environments.

Stacking capability: Supports SummitStack-V400 400Gbps high-speed stacking,
Up to 8 switches can be stacked to expand the network size.

Security features: Supports 802.1X authentication, port security, DoS attack protection, etc., to ensure network security.
