Extreme Networks X670V-48T Switch

Product manual:

X670V-48T Switch Product Features

Product Introduction
X670V-48T is a high-performance stackable 10 Gigabit Ethernet switch from the Extreme Networks Summit series, primarily designed for enterprise data centers and core networks. This switch provides high-density ports and flexible stacking capabilities, suitable for environments with high bandwidth and reliability requirements.

Main Features

Port configuration: 48 10GBASE-T RJ-45 ports, supporting adaptive speeds of 10/100/1000/10000 Mbps.

Combination ports: 4 combination ports, supporting 10GBASE-T or 10GBASE-X SFP+.

Upstream interface: 4 40GBASE-X QSFP+upstream ports, suitable for high-speed connection or stacking.

Stacking capability: Multiple switches can be stacked using SummitStack-V technology, with a stacking bandwidth of up to 320 Gbps.

Module Expansion: Provides VIM4 slot for installing VIM4-40G4X modules, adding 4 40GBASE-X QSFP+ports.

Management interface: includes 1 10/100/1000 Mbps management port and 1 serial console port, supporting remote and local management.

Power configuration: Supports dual redundant, hot swappable power modules, providing AC and DC power options.

Operating System: Runs ExtremeXOS and supports unified management and configuration.

Physical specifications

Dimensions: Height 4.4 cm, Width 44.1 cm, Depth 51.9 cm, suitable for 1U rack installation.

Weight: Approximately 7.0 kg.

performance metrics

Switching capacity: 1280 Gbps

Forwarding rate: 952 Mpps

MAC address table size: 128000 entries

Delay: less than 3.3 microseconds

Application scenarios

Enterprise Data Center Core Exchange

High performance computing and virtualization environment

Large scale stacking deployment

High bandwidth applications, such as high-definition video streaming or big data analytics

Precautions for use

Link and redundancy strategies need to be planned before stacking configurations.

Confirm that the bandwidth of the upstream and stacked ports meets the network traffic requirements.

Regularly upgrade firmware to ensure performance and security.

Extreme Networks X670V-48T Product details picture:

X670V-48T
