FCP270 P0917YZ Field Control Processor Module

Product manual:

FCP270 P0917YZ Field Control Processor Module Description
1、 Module positioning

Type: Field Control Processor (FCP)

Brand: Foxboro (under Schneider Electric)

System: Foxboro I/A Series, Evo DCS

Role: Core control unit (on-site CPU) in distributed control systems

It is equivalent to the brain of the on-site control layer, responsible for logical operations, data processing, and communication coordination.

2、 Main functions
1. Control logic execution

Execute continuous control, sequential control, and interlocking logic

Handling PID loops, timed tasks, and status judgments

Real time control and management of on-site equipment

2. Data collection and processing

Collect analog and digital signals from fieldbus module (FBM)

Perform data calculation, filtering, and state judgment

Support alarm, event, and historical data processing

3. Communication and Network

Communicate with the upper system and operation station through industrial Ethernet

Connected to multiple FBM modules via fieldbus

As a data hub between the on-site layer and the control network

4. Redundancy and high reliability

Support dual machine redundant configuration

Seamless switching in case of main processor failure to ensure continuous system operation

Suitable for critical processes and important equipment control scenarios

3、 Technical features

Industrial grade design: suitable for long-term continuous operation

Strong real-time performance: meets the requirements of process control for response speed

Strong scalability: can connect multiple FBM modules, flexible system scale

Stable and reliable: widely used in high demand industrial sites

FCP270 P0917YZ Product details picture:

FCP270 P0917YZ product video
