FORCE COMPUTERS CPCI-736 CPU board

Product manual:

Product Overview

FORCE COMPUTERS CPCI-736 is a CPU single board computer with CompactPCI (cPCI) architecture, designed specifically for industrial control, embedded systems, and high reliability applications. This board integrates high-performance processors, memory, and I/O interfaces, and can be used as the core control unit of the system. It is compatible with cPCI standard chassis and backplanes, making it suitable for modular system deployment.

Technical parameters (typical features)

Processor: Intel or PowerPC series (specific model varies depending on version), with a clock speed of up to several hundred MHz

Cache: Onboard Level 1/Level 2 Cache

Memory: onboard SDRAM, typically 64MB~512MB in capacity, expandable

Storage interface: onboard Flash/EEPROM, used for firmware and boot programs

Bus interface:

CompactPCI (cPCI) bus

Supports 32-bit/64 bit data transmission, PCI signal standard

I/O interface:

Multiple serial ports (RS-232/RS-422/RS-485)

Parallel port or GPIO

Ethernet interface (10/100 Mbps, optional Gigabit Ethernet)

Operating system support: VxWorks, Linux, Windows Embedded, etc

Power supply: cPCI backplane power supply, onboard voltage regulation design

Industrial grade design: supports wide temperature operation, anti vibration and anti impact capabilities

Application scenarios

Industrial Automation: PLC, Robotics, and Production Line Control Core

Embedded computing platform: data acquisition, processing, and real-time control

Communication system: switch, base station and edge computing node

Traffic Control: Railway, Subway Signal Systems and Dispatch Control

Testing and Measurement System: High speed Data Acquisition and Instrument Control

Military and Aerospace: Embedded Command and Task Processing Platform

FORCE COMPUTERS CPCI-736 Product details picture:

CPCI-736

FORCE COMPUTERS CPCI-736 product video
