Gasonics 06764002 Controller Board

Product manual:

Product Name: Gasonics 06764002 Controller Board
Component type: Controller PCB
Main function: Used in Gasonics plasma equipment to undertake key subsystems
Control logic execution and signal coordination for gases, radio frequencies, power supplies, machinery, etc., to achieve intelligent control of subsystems in automated process technology

1、 Core Control and Signal Processing
This control board receives commands issued by the main control system and executes corresponding control tasks, such as switching actuators, adjusting parameters, collecting status, and providing feedback.

Common control functions:

Control the operation of equipment such as solenoid valves, motors, sensors, etc

Process logic of management subsystem (such as gas switching or chamber operation)

Collect analog/digital signals and upload status

2、 Modular signal interface design
The 06764002 control board design supports multiple I/O interfaces, adapting to various signal input and output requirements of field devices,
Support hot swappable connections for easy maintenance and system integration.

Interface support types:

Digital Input/Output (DI/DO)

Analog input (AI) or feedback signal

TTL or dedicated communication signal (connected to the main control system)

3、 Integration with the upper system
This control board is usually used as an intermediate control layer, located on the upper main control board (such as ABX or Aura controller)
Plays a role in logical relay and signal coordination with lower level actuators.

System hierarchical structure:
Main control board → 06764002 controller board → execution components (solenoid valves, sensors, etc.)

Product details picture:

06764002
